Diaphragm switch with heavy duty .031” thick, black neoprene diaphragm, externally mounted with DPDT contact. Does not have hazardous location approvals.
| Means of Measurement | Pressure Switch |
|---|---|
| Measurement Type | Point Level |
| Medium | Solids |
| Voltage | Up to 250 VAC |
| Search Voltage | 24 VAC |
| Outputs | Relay DPDT 10 Amp - 250 VAC max |
| Outputs | Relay |
| Ambient Temperature | -40°F to +300°F (-40°C to +148°C) |
| Process Temperature | Up to +300°F (148°C) |
| Search Process Temperature | Below 300°F |
| Approvals | Ordinary Locations (non-hazardous) |
| Enclosure Material | Die cast aluminum |
