MR-H-110 - Mini-Rotary 110 VAC with insertable bayonet polycarbonate paddle, complete with SPDT contacts. This economical and compact mini rotary paddle level indicator is designed for controlling material levels in smaller bins and hoppers where other types of equipment simply won't fit.
| Means of Measurement | Rotary Paddle |
|---|---|
| Measurement Type | Point Level |
| Medium | Solids |
| Voltage | 110 VAC |
| Search Voltage | 110 VAC |
| Outputs | Relay SPDT |
| Outputs | Relay |
| Ambient Temperature | -4°F to +140°F (-20°C to +60°C) |
| Process Temperature | Up to +176°F (80°C) |
| Search Process Temperature | Below 250 °F |
| Approvals | Ordinary Locations (non-hazardous) |
| Enclosure Type | NEMA 1 |
| Enclosure Material | Plastic |
