The BinMaster PRO Remote 75' Power Pac delivers exceptional installation versatility by positioning electronics up to 75 feet away from the sensing probe—perfect for challenging environments like high-vibration zones, elevated vessels, or hard-to-access areas. It includes versatile 115 VAC/230 VAC power, intuitive “Quick-Set” calibration, adjustable time delay, and PRO-Shield technology to combat buildup and false signals. The rugged enclosure, complete with LED status feedback and DPDT relay output, ensures reliable performance with minimal upkeep.
NOTE: Triax cable for remote installation is required and must be ordered separately.
| Means of Measurement | Capacitance |
|---|---|
| Measurement Type | Point Level |
| Medium | Solids |
| Voltage | 115 VAC;230 VAC |
| Search Voltage | 110 VAC;220 VAC |
| Outputs | Relay DPDT 10 Amp - 250 VAC max |
| Outputs | Relay |
| Ambient Temperature | -40°F to +185°F (-40°C to +85°C) |
| Process Temperature | Up to +500°F (260°C) |
| Search Process Temperature | Below 450 °F |
| Approvals | Unlisted |
| Enclosure Type | NEMA 4X |
| Enclosure Material | Die cast aluminum |
| Mounting | 1.25" NPT |
| Conduit Entry | 0.75" NPT |
