main product photo

PROCAP II-3A Power Pac

Request a Quote
SKU
PC23A.

The BinMaster ProCap II-3A Power Pac elevates sanitary point-level detection with precision and ease, tailored for stringent food and dairy processing environments. Featuring a 115/230 VAC selectable power design, bright LED status indicator, and hassle-free “Quick-Set” calibration, it ensures rapid installation and intuitive monitoring. Its DPDT relay output with selectable fail-safe and adjustable time delays deliver dependable performance while minimizing false signals. Built to 3-A sanitary standards, it comes in a robust, powder-coated die-cast aluminum housing with triple-thread cover and dual conduit entries for secure, hygienic integration. The ProCap II-3A Power Pac offers unmatched reliability and versatility in clean-process applications.

Overview
Applications
Specs
Downloads
Accessories
Video

PROCAP capacitance probe: Your most versatile point level sensor

Get a custom capacitance probe built to your specifications right here in the USA. BinMaster assemblers will build your probes in-house to suit a wide variety of powders, solids, liquids, and slurries.

Choose your power requirements:

PROCAP I: Universal power supply 24 to 240 VAC/VDC

PROCAP II: Selectable 115/230 VAC

USA-made for accuracy and reliability under rigorous conditions:

Fail-Safe Operation: Sensor status light alerts to sensor status to prevent processing mishaps

False Reading Prevention: PRO-Shield ignores buildup on the probe or bridging between the sidewall and the probe

Sanitary Conditions: PROCAP I-3A & II-3A meet 3-A material and design standards for sanitary food and dairy processing

Get the right probe in the right length for your vessel and material:

  • Bare, Delrin, or Teflon sleeved, food grade, shielded or unshielded
  • Flush mount for bin walls, chutes, and conveyors
  • Custom length solid and flexible extensions

Plus, you get all this with every BinMaster PROCAP:

  • PRO-shield buildup prevention
  • Simple quick set, temperature stable calibration
  • Switch-selectable, high/low fail-safe
  • Adjustable time delays to 30 seconds to prevent false signals
  • Visual LED status light indicates covered, uncovered, or failed
  • Protection from RF interference
pro-remote-capacitance-probe
3D-overflow_1

Overflow Prevention
High level alerts to avoid over-filling vessel

Shop Overflow Prevention
material-outage

Material Outages
Low level alerts eliminate empty conditions

Shop Outage Prevention
chute-clogged

Plugged Chutes
Detect when chutes are clogged with material

Shop Plugged Chutes
process-control

Process Control
Switching relay to turn a process off or on

Shop Process Control
conveyor-damage

Conveyor Overload
Prevent jamming or damaging conveyors

Shop Conveyor Overload
More Information
SKUPC23A.
Means of MeasurementCapacitance
Measurement TypePoint Level
MediumSolids
Voltage 24 to 240 VAC/VDC Universal
OutputsRelay DPDT 10 Amp - 250 VAC max
Ambient Temperature-40°F to +185°F (-40°C to +85°C)
Process TemperatureUp to +176°F (80°C)
ApprovalsUnlisted
Enclosure TypeNEMA 4X, NEMA 5, NEMA 9, NEMA 12
Enclosure MaterialDie cast aluminum
Mounting1.25" NPT
Conduit Entry0.75" NPT

Mount Plates

Accessories

Introductory video about capacitance probes.

How to calibrate and wire a capacitance probe.

How to wire a capacitance probe to a light.

Mini capacitance probes for point level detection.

ProCap Brochures

ProCap Manuals

ProCap Spec Drawings
