Tilt switch with ATEX approvals for high-level limit switch application for stationary mounting. Certified for Class II Groups E, F, and G.
| Means of Measurement | Tilt Switch |
|---|---|
| Measurement Type | Point Level |
| Medium | Solids |
| Voltage | Up to 250 VAC |
| Outputs | Relay SPDT |
| Ambient Temperature | -40°F to +185°F (-40°C to +85°C) |
| Process Temperature | Up to +176°F (80°C) |
| Approvals | CSA/US Class I, Groups C & D and Class II, Groups E, F & G |
| Enclosure Type | NEMA 4X, NEMA 5, NEMA 12, IP 66 |
| Enclosure Material | Die cast aluminum |
| Mounting | 1.25" NPT |
| Conduit Entry | 0.75" NPT |
